Thermocouples Coated to Survive Longer

Introducing EtchDefenderTM Technology.

Only from Conax.

Coated quartz thermocouples for ASM®‡ EPSILON®‡ reactors last up to 3X longer



‡ ASM® and EPSILON® are registered trademarks of ASM International. Neither Conax Technologies nor its products are affiliated with, licensed, approved by or sponsored by ASM International.

Conax introduces an exclusive, patented solution for extending the life of quartz thermocouple sheaths in ASM®‡ EPSILON®‡reactors.

‡ ASM® and EPSILON® are registered trademarks of ASM International. Neither Conax Technologies nor its products are affiliated with, licensed, approved by or sponsored by ASM International.

This cutting-edge EtchDefenderTM technology has been tested both in the laboratory and in a production environment at a major wafer manufacturing facility.



EtchDefenderTM advantages

Testing has shown:

  • No particulation—EtchDefenderTM coating is well adhered and will not flake from the quartz substrate, which could cause particle contamination to the wafer.
  • Durability—The coating does not decompose, out-gas or sublimate under vacuum at high temperature.
  • Slower devitrification—The coating greatly slows the devitrification process typical of quartz sheaths used in the EPSILON®‡ by retarding the loss of oxygen from the SiO2 quartz sheath at temperatures more than 900°C.
  • ‡ ASM® and EPSILON® are registered trademarks of ASM International. Neither Conax Technologies nor its products are affiliated with, licensed, approved by or sponsored by ASM International.
  • Slower erosion—The coating greatly retards the erosion process caused by hot corrosive gases flowing at high concentrations and velocities. This is most relevant in extending the life of the Center Thermocouple.
  • Significantly longer life—The coating will allow quartz sheaths to last up to three times longer.

Click here to download our White Paper.

Precious Metals Reclamation

Conax Technologies manufacturers, and offers reclaim credit for, platinum/rhodium precious metals thermocouples. These are commonly called Type-S, Type-R or Type-B thermocouples. To send either thermocouples or precious metals wire to Conax for reclaim, you must first contact Conax to issue an RMA (Return Materials Authorization) number to you. When we receive your shipment, we will disassemble, remove and weigh the wire. We will then calculate the value based on the current market pricing of platinum and rhodium. This value is given to the returning company in the form of a credit to apply against current or future invoices. Please contact your Conax sales person for more details.

Platinum Reclaim Program

The Development of EtchDefender™ technology from Conax Technologies on Vimeo.

View detailed video here.

ASM®‡ EPSILON®‡ single-wafer Epi Tool



‡ ASM® and EPSILON® are registered trademarks of ASM International. Neither Conax Technologies nor its products are affiliated with, licensed, approved by or sponsored by ASM International.

The epitaxial process takes place at one of the highest temperatures of any in the manufacture of integrated circuits. Because the ASM®‡ EPSILON®‡ single-wafer epitaxial tool uniquely utilizes thermocouples that are installed inside the reactor chamber for process control, the thermocouples are often exposed to two temperature cycles that can range from 600°C to 1200°C for each wafer processed.

‡ ASM® and EPSILON® are registered trademarks of ASM International. Neither Conax Technologies nor its products are affiliated with, licensed, approved by or sponsored by ASM International.

The second temperature cycle is the etch process, which is used to clean the chamber and all the internal components with hydrochloric acid at extremely high temperatures. As thermocouples are subjected to these cycles and corrosive hydrochloric acid etches, the quartz sheath is attacked and ultimately fails, requiring a maintenance cycle to replace them. Our goal was to develop a solution that protects the quartz sheath during the etch process and slows devitrification to extend its life and eliminate maintenance cycles needed solely to replace thermocouples.



Increased yield and decreased cost of ownership

Using TCs coated with EtchDefenderTM allows a tool to run continuously and reduces maintenance cycles, resulting in:

  • Increased process uptime
  • Reduced process variation, so more wafers can be produced per tool with higher consistency
  • Reduced labor and increased safety
  • Decreased risk of technicians igniting pyrophoric deposits as a result of reduced maintenance requirements
  • Decreased exposure of the chamber to oxygen, resulting in less time needed to purge the oxygen from all surfaces

Request a Quote

Our complete line of thermocouples for ASM®‡ EPSILON®‡ Reactors is now available with EtchDefenderTM coating.
Call +1 800 223 2389 or request a quote to find out how EtchDefenderTM can increase uptime and lower costs for you.
